Figure 122. The SAN Volume Controller 2145-8G4 disk-drive backplane connectors
9. Press the locking tab
slightly. Disconnect the power cable and remove the back plate.
2
Figure 123. The SAN Volume Controller 2145-8G4 SATA disk drive and back plate
1
Locking tab
2
Mounting channel
120
IBM SAN Volume Controller Hardware Maintenance Guide
1
, which is shown in Figure 123, and lift the back plate out of the node
1
2
