San Volume Controller 2145-8G4 Air Baffle - IBM SAN Volume Controller Hardware Maintenance Manual

2
USB cable
3
CD-RW cable
4
Light path cable
5
Interposer card
6
Fan 3
7
USB cable connector
8
Video cable connector
9
CD-RW connector
10
Air baffle
11
Light path cable connector
5. Reconnect the video cable
6. Replace the air baffle
routed correctly, as shown in Figure 222, and not obstructing the fan doors.
2
1
Figure 222. SAN Volume Controller 2145-8G4 air baffle
1
Cable routing slot
2
Air baffle
3
Baffle pins
4
Baffle mounting holes
7. Replace fan 3 as shown in Figure 223 on page 202.
8
, the USB cable
2
. It is easier to do this if you remove fan 2. Ensure that all the cables are
3
4
7
and the CD/DVD cable
Chapter 2. Removing and replacing parts
9
to the system board.
201
