Figure 5 shows how the different parts for the SAN Volume Controller 2145-8F2 are assembled.
16
15
14
Figure 5. Exploded view of the SAN Volume Controller 2145-8F2 node
Table 15 provides the part numbers and a brief description of the frame assembly parts that are labeled in
Figure 5. The frame assembly comprises all of the parts except the service controller and fibre-channel
cards. These parts are listed in Table 16 on page 15.
Table 15. SAN Volume Controller 2145-8F2 frame assembly
Assembly index
-1
-
-3
-4
-6
14
IBM SAN Volume Controller Hardware Maintenance Guide
12
13
Part number
64P7934
23K4219
64P8332
23K4211
90P1957
90P5281
1
2
3
4
5
6
7
8
9
10
11
Units Description
1 Frame assembly
1 Top cover
1 80GB SATA HDD
1 Riser card, PCI (full height)
1 Riser card, PCI (low profile)
2 Heat sink
