Items Not Included In The San Volume Controller 2145-8F2 Frame Assembly - IBM SAN Volume Controller Hardware Maintenance Manual

Table 15. SAN Volume Controller 2145-8F2 frame assembly (continued)
Assembly index
-7
-8
-
-
-9
-10
-11
-
-
-
-
-12
-13
-15
-16
-
Table 16. Items not included in the SAN Volume Controller 2145-8F2 frame assembly
Assembly index
-2
-5
-
-14
-
-
-
-
-
-
Part number
13M8293
90P5282
90P5284
23K4209
32R1730
24R2698
24R2640
23K4515
33F8354
33P2352
25R4052
23K4992
23K4490
23K4217
33P2335
73P2870
Part number
64P7783
64P7813
23R2770
64P7874
64P7940
23K4218
39M5699
39M5700
39M5701
12R9321
Units Description
2 Microprocessor, 3.0 GHz
1 Heat sink retention module
1 Chassis
1 Cage assembly
1 System board
2 VRM, 1U/75A
1 Power supply assembly
1 Power backplane
1 Battery, 3.0V
1 Cable, fan power
1 Cable, signal, front panel
1 Fan holder with fan
backplanes
1 Operator information panel
3 Fan, 40×40×28
4 Fan, 40×40×56
8 Memory, 1 GB ECC DRR2
Units Description
1 Fibre-channel HBA (full
height)
1 Fibre-channel HBA (low
profile)
1 Fibre-channel SFP
transceiver
1 Service controller
1 Input power cable
assembly, (SAN Volume
Controller 2145-8F2 to the
2145 UPS-1U)
1 Kit, toolless rail
External fibre-channel
cable, LC–LC, 1.0 m (3.3 ft)
External fibre-channel
cable, LC–LC, 5.0 m (16.4
ft)
External fibre-channel
cable, LC–LC, 25.0 m (82 ft)
External fibre-channel
cable, LC–SC/LC, 1.0 m
(3.3 ft)
Chapter 1. Parts listing
