9. Disconnect the connectors from the system board, which are shown in Figure 273. From the right
front side of the system board, remove the following:
a. The fan 3 connector
b. The fan 4 connector
c. The fan 5 connector
d. The fan 6 connector
e. The uninterruptible power supply cable connector
f. The video cable connector
8 7
Figure 273. Connectors on the right front side of the SAN Volume Controller 2145-8G4 system board
10. Remove the remaining cables from the system board:
a. The CD-RW ribbon cable connector
b. The light path ribbon cable connector
All cables should now have been removed from the system board. You do not need to disconnect the
disk power cable connector
251.
250
IBM SAN Volume Controller Hardware Maintenance Guide
5
by pressing the release latch in the center and then pulling up.
6
by pressing the release latch in the center and then pulling up.
7
by pressing the release latch in the center and then pulling up.
8
by pressing the release latch in the center and then pulling up.
3
.
6 5
1
by gently pulling the connector upward.
2
by gently pulling the connector upward.
1
on the power backplane
4
.
2
, which are shown in Figure 274 on page
4
3
2
1
