Chapter 9 Options

Fan Fold Guides

Media Roll Retainer

Edge Guide

3-inch Adapter

Label Taken Sensor

76
The fan fold guides are useful for providing a more exact guiding
of the media, when the supply is placed outside the media
compartment, for example a stack of fan-folded tickets. The
guides come as a fi eld-installable kit with installation instructions.
The guides can be fi tted in the upper or lower slot in the rear
plate.
Instructions for loading the media is included in the section
"External Supply" in Chapter 4, "Media Load."
The media roll retainer is intended for applications where the
media may become misaligned on the media supply hub. The
plastic wing-shaped retainer is simply pressed onto the media
supply hub outside the media roll. No tools are required.
For demanding applications, the edge guide at the rear part of the
print unit can be supplemented with a second edge guide fi tted
on the slack absorber. This guide is included in the package.
The 3-inch/76 mm adapter is included in the package and makes
it possible to use media rolls with 3 inch/76 mm inner diameter
cardboard cores.
The adapter is pressed onto the media supply hub and is held
in place by a screw. When fi tting the adapters, make sure that
the screw hits a rounded plastic surface, not a metal leaf spring.
Illustrations of how to load the media using the adapter can be
found in Chapter 4, "Media Load."
The Label Taken Sensor (LTS) is a photoelectric sensor fi tted to
the center section inside the front door. It allows the printer's
fi rmware to detect if the latest printed label, ticket, tag etc. has
been removed before printing another copy.
The label taken sensor is usually factory-fi tted, but is also avail-
able as a kit for installation by an authorized service technician. It
cannot be fi tted in combination with a paper cutter.
The LTS can be enabled or disabled by means of the instruc-
tions LTS& ON and LTS& OFF respectively in Intermec
Fingerprint and the Intermec Direct Protocol.
