Print Unit
Printhead Lock
Thermal Printhead
Tear Bar
Platen Roller
Liner Drive Roller
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
The print unit features a high performance 8 or 11.81 dots/mm
(203.2 or 300 dots/inch) thermal printhead with quick-mount fi ttings
to facilitate replacement.
Printhead Lift Lever
Chapter 3
Installation
Printhead Pressure Adjustment
21
