Chapter 2
Installation
Print Unit
Pressure Arm
Thermal Printhead
Tear Bar
Upper Label Stop Sensor Guide
(removable)
Lower Label Stop Sensor Guide
(removable)
12
The print unit features a high-performance 12 dots-per-mm
( 300 dots-per-inch) thermal printhead with quick-mount fi t-
tings to facilitate replacement.
Label Stop Sensor
Position Adjustment
Intermec EasyCoder 501 XP – User's Guide
Pressure Arm Locking Knob
Printhead Pressure
Adjustment Knob
Edge Guide
Printhead Lift Lever
