Scanner Adjustment

1. Set an A3-sized paper in the cassette.
2. Set the printing margin to "0 mm" in Unique Switch F:2.
3. Print the test pattern (Ladder pattern).
4. Confirm that four black squares are printed without lacking. The square is 10 mm
If it is lacking, proceed to step 5. Otherwise, skip to step 6.
5. Adjust the start and end point to print of the cassette you loaded the A3-sized paper in Machine
Parameter K, M, S, U.
6. Make a copy (100%) with an A3-sized paper.
7. Compare the copy with the original document and confirm that the copy is printed correctly
If it is not printed correctly, proceed to step8. Otherwise, skip to step 9.
8. Adjust the scanning position in Machine Parameter B.
9. After finishing the adjustment, set the printing margin to "4 mm" in Unique Switch F:2.
Printing position Adjustment
1. Adjust the scanner.
2. Set the printing margin to "0 mm" in Unique Switch F:2.
3. Make a copy with a cassette you want.
4. Confirm that it is printed at center of the paper.
If not, proceed to step 5. Otherwise, skip to step 6.
5. Adjust the start and end point to print of the cassette you used in Machine Parameter K, M, S, U.
In the case of the rotate printing, adjust it in Machine Parameter L, N, T, V.
6. Set the printing margin to "4 mm" in Unique Switch F:2.
7. Adjust the each margin to set the printing margin to "4 mm", if necessary.
In the case of the rotate printing, adjust it in Machine Parameter P, R, X, Z, if necessary.
8. Repeat step 3 7 for other cassettes.
3-78
10 mm.
