Hw Monitor Pane Toolbar; Components - Polycom 1500 Administrator's Manual

RealPresence Collaboration Server (RMX) 1500/1800/2000/4000 Administrator's Guide
Field
Type
Status
Temperature
Voltage

HW Monitor Pane Toolbar

The following buttons appear in the tool bar of the Hardware Monitor:
HW Monitor Pane Tool Bar Buttons
Button Name
System Reset
System Shut Down
System Start Up
Shelf Manager
Logger Mode
Viewing the Properties of RealPresence Collaboration
Server (RMX) 1500 Hardware Components
The properties displayed for the hardware components will vary according to the type of component viewed.
These component properties can be grouped as follows:
● MCU Properties (RealPresence Collaboration Server (RMX) 1500)
● Card Properties (MPMx/MPMRx, CNTL, RTM IP, RTM ISDN)
Polycom®, Inc.
Description
The type of hardware component card.
The current status of the HW component; Normal, Major, Critical, Resetting,
Diagnostics, or Empty.
Monitors the temperature of the hardware components; Normal, Major and Critical.
Note: Critical condition invokes a system shut down.
The voltage threshold of the hardware component; either Normal or Major.
Description
Resets and restarts the system. Resetting saves settings and information
that you changed in the system, i.e. IP Services, etc...
Shuts down the system into a standby mode. When the user in the
Collaboration Server Manager/Client presses the System Shut Down
(red) button in the Hardware Monitor tool bar, the system should enter a
standby mode and the LED turns ON. Only the media and control unit
cards are in a standby mode. Shelf Manager remains active.
Turn the system OFF/ON to exit the standby mode.
Starts up the system.
Note: This button is only displayed when connecting directly to the Shelf
Management server.
In the HW Monitor this opens the Shelf Management login window.
In the Shelf Management HW Monitor this sets the MFA, CPU and
Switch (Cards: MPMx/MPMRx, CNTL and RTM IP) into diagnostic mode.
For more information, see
Server (RMX) 1500/2000/4000)
Diagnostics Tests selection and Tests monitoring.
Note: This button is only displayed when connecting directly to the Shelf
Management server and logged in as a special support user.
Diagnostic Mode (RealPresence Collaboration
.
