RealPresence Collaboration Server (RMX) 1500/1800/2000/4000 Administrator's Guide

Configuring and Modifying Precedence Domains and DSCP Values

The Precedence Domains and DSCP values for each Precedence Domain can be configured and
modified per MCU.
To configure Precedence Settings:
1 On the RMX menu, click Setup > Precedence Settings
The Precedence Settings dialog box is displayed.
2 Optional: Modify the values if required.
Precedence Settings - Domains, Levels and DSCP Values
Field
Use Precedence
Precedence Domain
Domain Name
Signaling DSCP
Polycom®, Inc.
Description
Select or clear the check box to enable or disable Precedence.
Default: Cleared (Precedence disabled)
Select the Precedence Domain to be modified, 1 or 2, from the drop-down menu.
Possible Values: 1 / 2
Enter the required Domain Name.
Modify the DSCP value of the Signaling DSCP. A single Signaling Proxy is used
for all Precedence Levels.
Default: 40
Range: 0 - 63
838
