RealPresence Collaboration Server (RMX) 1500/1800/2000/4000 Administrator's Guide
 CTS 1300
 CTS 3010
The deployment architecture in
using SIP shows a company that has a mixture of Polycom, Cisco and Microsoft endpoints, room systems
and telephony equipment that needs to enable multipoint calls between all its video and audio endpoints
using the Collaboration Server as the conference bridge.
This solution enables Polycom, Microsoft and Cisco users, each within their own environment, to participate
in the same conference running on an MCU.
In the solution described in
using SIP:
● DMA is required as all calls are dial-in to Virtual Meeting Rooms (VMR) provisioned on the DMA.
● Microsoft and Cisco clients dial the same VMR number to connect to the conference.
● Dial- out calls directly from the RMX are not supported.
● Lync Clients cannot share content with CTS
● SIP trunks are required to the DMA from:
 MS Lync as a Static Route.
 CUCM

Deployment Architecture

● DMA is required as all calls are dial-in to Virtual Meeting Rooms (VMR) provisioned on the DMA.
● Microsoft and Cisco clients dial the same VMR number to connect to the conference.
● Dial- out calls are not supported
● Lync Clients can not share content with CTS
● SIP trunks are required to the DMA from:
 MS Lync as a Static Route.
 CUCM
Polycom®, Inc.
Single company with Polycom and Cisco Infrastructure - Polycom endpoints
Single company with Polycom and Cisco Infrastructure - Polycom endpoints
1111
