RealPresence Collaboration Server (RMX) 1500/1800/2000/4000 Administrator's Guide
Field
Serial Number
Card Part Number
Mezzanine B
Hardware
Version
Serial Number
Card Part Number
2 Click the Event Log tab to view a log of events recorded by the system on the HW component.
For more information, see
3 Click the Active Alarms tab to view alarms related to the hardware component, i.e. temperatures
and main power sensors.
For more information, see "Active Alarms" on
to faults and errors detected on the Collaboration Server by sensors. The Active Alarms dialog box
is divided into two sections: HW Alarm List and SW Alarm List.
4 Click Close to return to the HW Monitor pane.

To View the Supporting Hardware Components Properties:

1 In the Hardware Monitor pane, either double-click or right-click and select properties for the desired
supporting hardware component.
The component's properties dialog box will appear with the General Info tab displayed.
Backplane Properties:
The Collaboration Server unit's backplane properties provides the following information:
Backplane Properties - General Info
Field
HW Version
SW Version
Polycom®, Inc.
Description
The Mezzanine A hardware component's serial number.
The part number of the Mezzanine A hardware component's board.
The Mezzanine B hardware component's version number.
The Mezzanine B hardware component's serial number.
The part number of the Mezzanine B hardware component's board.
MCU Properties - Event Log
The Active Alarms dialog box displays fields that relate
Description
The Backplane's current hardware version.
The Backplane's current software version.
on page 17.
.
863
