14. Verify that the application has begun loading the GUI firmware on the Guardio/Vesta Charger.
See Figure 70.
Figure 70: Bootstraploader Screen Indicating GUI Firmware Upload has Begun
15. When the firmware update has been completed, verify that the application displays a message
"The firmware has been successfully downloaded to the device". Tap OK. See Figure 71.
16. Tap the X at the top right corner of the Bootstraploader Tool for Charger Firmware Upgrade
window to close it.
Figure 71: Message Indicating Firmware Successfully Loaded onto Guardio/Vesta Charger
82
