Impulse Dynamics OPTIMIZER Smart Mini Instructions For Use Manual page 67

To save a PDF copy of the Alerts Trend:
1. Insert a USB flash drive into the USB port on the left side of the Intelio
2. Tap the Printer icon at the top right of the Alerts Trend screen.
3. When the Report Viewer window appears, tap the PDF icon at the top
4. If successful, a pop-up window will appear indicating that the report was
To close the Alerts Trend screen, tap the "X" at the top right corner of the Alerts
Trend screen.
The Alerts Trend Report is saved in the Reports folder of the USB flash drive.
The file name of the Alerts Trend Report has the following format:
AlertsTrend_NNNNNN_DDMMYYYYhhmmss
Where:
•
•
•
•
•
•
•
3.16 Continuous Mode
Continuous Mode allows the user to override scheduled CCM therapy delivery and initiate
continuous CCM therapy delivery.
Note: The Continuous Mode option is only available when the OPTIMIZER Smart Mini IPG is not
in OOO mode and CCM Therapy Mode is set to ON.
To start continuous CCM therapy delivery:
1. If necessary, initiate a link with OPTIMIZER Smart Mini IPG
a. Place (or replace, if necessary) the Intelio Programming Wand over the OPTIMIZER
Smart Mini IPG implant site
b. Tap the Start OPTIlink button on the OPTIlink Session Pane
2. Tap the Diagnostics button on the Menu Bar
3. Select the Continuous Mode tab
4. On the Continuous Mode panel, tap the Start Continuous Mode button
The OPTIMIZER Smart Mini IPG will begin delivering continuous CCM therapy delivery for up to
one hour.
Note: The CCM Status in the Marker Sub-Pane will be orange, indicating that CCM therapy is in
Continuous Mode.
Figure 54: Marker Sub-Pane with CCM Therapy in Continuous Mode
programmer tablet PC
right of the window.
saved in the USB drive. Tap Close to close the pop-up window.
NNNNNN = serial number of device
DD = day the file was created
MM = month the file was created
YYYY = year the file was created
hh = hour the file was created
mm = minute the file was created
ss = second the file was created
57
