7. Electrical Interface
7.6. General Purpose Analog I/O
Description The analog I/O interface is the green terminal. It is used to set or measure voltage (0-
10V) or current (4-20mA) to and from other equipment.
The following directions is recommended to achieve the highest accuracy.
Electrical In the GUI you can select input modes. The electrical specifications are shown below.
Specifications
Terminals
Analog Input in current mode
[AIx - AG]
[AIx - AG]
[AIx - AG]
Analog Input in voltage mode
[AIx - AG]
[AIx - AG]
[AIx - AG]
Analog Output in current mode
[AOx - AG]
[AOx - AG]
[AOx - AG]
Analog Output in voltage mode
[AOx - AG]
[AOx - AG]
[AOx - AG]
[AOx - AG]
User Manual
•
Use the AG terminal closest to the I/O. The pair share a common mode filter.
•
Use the same GND (0V) for equipment and Control Box. The analog I/O is not
galvanically isolated from the Control Box.
•
Use a shielded cable or twisted pairs. Connect the shield to the GND terminal at
the terminal called Power.
•
Use equipment that works in current mode. Current signals are less sensitive to
interferences.
Parameter Min
Current 4
Resistance -
Resolution -
Voltage 0
Resistance -
Resolution -
Current 4
Voltage 0
Resolution -
Voltage 0
Current -20
Resistance -
Resolution -
69
Typ Max Unit
- 20 mA
20 - ohm
12 - bit
- 10 V
10 - Kohm
12 - bit
- 20 mA
- 24 V
12 - bit
- 10 V
- 20 mA
1 - ohm
12 - bit
