ISA Connectors

Pin Signal Name
B1 GND
B2 RSTDRV
B3 Vcc
B4 IRQ9
B5 -5V
B6 DRQ2
B7 -12 V
B8 0WS#
B9 +12 V
B10 GND
B11 SMEMW#
B12 SMEMR#
B13 IOW#
B14 IOR#
B15 DACK3#
B16 DRQ3
B17 DACK1#
B18 DRQ1
B19 REFRESH#
B20 SYSCLK
B21 IRQ7
B22 IRQ6
B23 IRQ5
B23 IRQ5
B24 IRQ4
PowerMate Pro150 System
Pin Signal Name
A1 IOCHK#
A2 SD7
A3 SD6
A4 SD5
A5 SD4
A6 SD3
A7 SD2
A8 SD1
A9 SD0
A10 IOCHRDY
A11 AEN
A12 SA19
A13 SA18
A14 SA17
A15 SA16
A16 SA15
A17 SA14
A18 SA13
A19 SA12
A20 SA11
A21 SA10
A22 SA9
A23 SA8
A23 SA8
A24 SA7
Continued
7-19
