AMIBIOS in a flash memory device supports system setup and PCI
auto-configuration
Expansion slots for up to six add-in boards
Three dedicated PCI slots
Two dedicated ISA-bus slots
One "combination" slot for either a PCI or an ISA add-in board
180 watt continuous (200 watt peak) power supply switch-selectable for
115 and 230 V ac operation
Two RS-232C-compatible 9-pin serial connectors
One multimode, 25-pin Centronics®-compatible parallel port
Two peripheral bays:
One bay that holds up to three 3.5-inch drives (one externally-
accessible, two internal access only)
One externally accessible bay for installing 5.25-inch drives (up to
three half-height drives or one half-height plus one full-height drive)
One 1.44 MB, 3.5-inch high-density diskette drive installed
PS/2®-style keyboard and mouse connector
Speaker mounted on the chassis
Password protection and padlock slot for system security
Most models include a:
1.6 GB IDE hard disk drive installed
Six-speed CD-ROM reader installed
Pair of external speakers
Microphone
Graphics controller card installed
Audio/sound card installed
SCSI interface card installed.
Some models include additional cards and peripherals.
1-2
Product Description
