System Board Components

P
O
A. Pentium Pro microprocessor
B. MIC Memory interface components
C. Memory controller data path chip
D. Power connector
E. OMC DRAM control chip
F. OPB PCI Bridge component
G. Front panel I/O connectors
H. Floppy drive connector
I. Primary PCI IDE connector
J. Secondary PCI IDE connector
K. On-board speaker
L. I/O controller
PowerMate Pro150 System
Q R S
L K J I
N M
Figure 5-1. System Board Components
M.
N.
O.
P.
Q.
R.
S.
T.
U.
V.
W.
T
V
U
H G
OM04089
Configuration jumper block
Card slot fan connector
Auxiliary hard drive LED connector
PIIX PCI ISA/IDE accelerator
SIMM sockets
Battery
Serial port 2 connector
Parallel port connector
PS/2 Keyboard/Mouse connectors
Serial port 1 connector
CPU Fan Connector
W
A
B
C
D
E
F
5-3
