Supported Simm Sizes; Memory Options For Simm Sockets - NEC POWERMATE PRO150 Manual

Total Memory Size
of SIMM
4 Mbytes
8 Mbytes
16 Mbytes
32 Mbytes
Notes
The board supports parity (x 36) or non-parity (x32) SIMMs.
Your system ships with non-parity SIMMs. Error checking
and correction (ECC) is supported with parity SIMMs.
There is no ECC with non-parity SIMMs.
All SIMMs must be tin lead, 72-pin, with 60 ns fast page-
mode DRAMs.
All SIMM socket sites must contain the same size SIMMs.
Table 5-2. Memory Options for SIMM Sockets
For a total
system
memory of
8 MB
16 MB
16 MB
32 MB
32 MB
64 MB
64 MB
128 MB
5-14
Table 5-1. Supported SIMM Sizes
SIMM configuration
(without parity)
1M x 32
2M x 32
4M x 32
8M x 32
Install a 72-pin SIMM of the following
size in both sockets of socket pair 1
4 MB (8 MB total in socket pair 1)
4 MB (8 MB total in socket pair 1)
8 MB (16 MB total in socket pair 1)
8 MB (16 MB total in socket pair 1)
16 MB (32 MB total in socket pair 1)
16 MB (32 MB total in socket pair 1)
32 MB (64 MB total in socket pair 1)
32 MB (64 MB total in socket pair 1)
Installing and Configuring System Board Options
SIMM configuration
(with parity)
1M x 36
2M x 36
4M x 36
8M x 36
Install a 72-pin SIMM of the following
size in both sockets of socket pair 0
Empty
4 MB (8 MB total in socket pair 0)
Empty
8 MB (16 MB total in socket pair 0)
Empty
16 MB (32 MB total in socket pair 0)
Empty
32 MB (64 MB total in socket pair 0)
