NEC POWERMATE PRO150 Manual page 138

PCI Connectors
Pin Signal Name
A22 AD28
A23 AD26
A24 GND
A25 AD24
A26 AD22 (IDSEL) B26
A27 3.3 V
A28 AD22
A29 AD20
A30 GND
A31 AD18
7-22
Pin Signal Name Pin
B22 GND A53
B23 AD27 A54
B24 AD25 A55
B25 3.3 V A56
CBE3# A57
B27 AD23 A58
B28 GND A59
B29 AD21 A60
B30 AD19 A61
B31 3.3 V A62
Signal Name Pin Signal Name
3.3 V B53 AD7
AD6 B54 3.3 V
AD4 B55 AD5
GND B56 AD3
AD2 B57 GND
AD0 B58 AD1
Vcc B59 Vcc
SREQ64# B60 SACK64#
Vcc B61 Vcc
Vcc B62 Vcc
Technical Reference
