PCI Connectors

Pin Signal Name
A1 GND
A2 +12 V
A3 No Connect
A4 No Connect
A5 Vcc
A6 PCIINT3#
A7 PCIINT1#
A8 Vcc
A9 Reserved
A10 Vcc
A11 Reserved
A12 GND
A13 GND
A14 Reserved
A15 SPCIRST#
A16 Vcc
A17 GNT#
A18 GND
A19 Reserved
A20 AD30
A21 3.3 V
PowerMate Pro150 System
Pin Signal Name Pin
B1 -12 V A32
B2 No Connect A33
B3 GND A34
B4 No Connect A35
B5 Vcc A36
B6 Vcc A37
B7 PCIINT2# A38
B8 PCIINT4# A39
B9 No Connect A40
B10 Reserved A41
B11 No Connect A42
B12 GND A43
B13 GND A44
B14 Reserved A45
B15 GND A46
B16 PCLKE A47
B17 GND A48
B18 REQA# A49
B19 Vcc A50
B20 AD31 A51
B21 AD29 A52
Signal Name Pin Signal Name
AD16 B32 AD17
3.3 V B33 CBE2#
FRAME# B34 GND
GND B35 IRDY#
TRDY# B36 3.3 V
GND B37 DEVSEL#
STOP# B38 GND
3.3 V B39 PLOCK#
SDONE B40 PERR#
SBO# B41 3.3 V
GND B42 SERR#
PAR B43 3.3 V
AD15 B44 CBE1#
3.3 V B45 AD14
AD13 B46 GND
AD11 B47 AD12
GND B48 AD10
AD9 B49 GND
KEY B50 KEY
KEY B51 KEY
CBE0# B52 AD8
Continued
7-21
