Removing A Drive From The 3.5-Inch Drive Bay; Installing An Internal Drive - NEC POWERMATE PRO150 Manual

A
Figure 4-10. Installing an Internal Drive

Removing a Drive from the 3.5-inch Drive Bay

1. Observe the precautions in "Before You Begin."
2. Disconnect the data cables and power cables from any drives in the
3.5-inch drive bay.
3. Remove the 3.5-inch drive bay.
4. Remove the four screws that attach the drive to the 3.5-inch drive bay.
5. Remove the drive from the bay and place it on an antistatic surface.
6. Replace the 3.5-inch drive bay.
7. Replace the data cables and power cables on any remaining drives in the
3.5-inch drive bay.
PowerMate Pro150 System
B
C
OM04078
4-19
