How to Disable Access to the Setup Program

To prevent access to the Setup program, do the following:
1. Turn off power and remove the system cover.
2. Move the jumper to the position shown below.
UP
A B
C D E
DOWN
3. Replace the system cover and turn power back on.
To enable access to the setup program, move the jumper to the position
shown below.
UP
A B C D E
DOWN

Recovery Boot Enable Jumpers

If the BIOS is corrupted during a BIOS upgrade, this jumper enables you to
boot the system and recover the BIOS. Appendix A tells how and when to
use the recovery boot enable jumpers.
UP
A B C D E
DOWN
UP
A B
C D E
DOWN
PowerMate Pro150 System
Setup program access disabled.
G H
F I
Setup program can be accessed.
(Default)
F G H I
Recovery boot enable
F G H I
Normal (Default)
G H
F I
5-9
