How to Clear CMOS RAM
This procedure should be done after the system BIOS is updated.
!
CAUTION
Do not use this procedure if your system is running
Windows 95. Clearing CMOS RAM after a BIOS upgrade
erases the Plug and Play data in the CMOS RAM. To clear
CMOS RAM on a Windows 95 system, press the <F5> key
from anywhere in the Setup program. This resets all Setup
options to their defaults. See Chapter 3 for information on
the Setup program.
1. Turn off power and remove the system cover.
2. Move the jumper to the position shown below.
UP
A B
C
D E
DOWN
3. Turn on power and allow the system to boot.
4. Turn off power.
5. Move the jumper back to the default position shown below to restore
normal operation.
UP
A B
C
D E
DOWN
6. Replace the system cover and turn the power back on.
5-8
Reset CMOS settings to default
CMOS RAM values.
G H
I
F
Normal mode (Default)
G H
I
F
Installing and Configuring System Board Options
