A
Figure 4-14. Removing the Power Supply
Installing the Power Supply
!
WARNING
This procedure should be done only by technically qualified
personnel. Unplug the system before doing the procedures
described here. Failure to disconnect the power before you open
the system can result in personal injury or equipment damage.
1. Observe the precautions in "Before You Begin."
2. Place the power supply in the chassis.
3. Slide the power supply to the rear of the chassis until it is flush with the
back panel.
4. Insert and tighten the three screws that secure the power supply to the
back panel.
5. Connect the power connector to the system board.
6. Connect the power connectors to any peripherals.
PowerMate Pro150 System
B
OM04198
4-25
