Keyboard and Mouse Connectors

6
4
PS/2-style Keyboard/Mouse Connectors
Pin
1
2
3
4
5
6
Note
You can plug the mouse and keyboard into either of the
PS/2-style connectors. The system automatically detects
the presence of the keyboard and mouse at boot up.
PowerMate Pro150 System
5
3
2 1
Signal Name
Data
No connect
Ground
+5 V (fused)
Clock
No Connect
O M0 433 0
