Figure 7-4 Connecting UPS cables
----End

7.5 Installing Communications Cables

7.5.1 Installing an FE Communications Cable

Step 1 Connect the FE communications cable to the WAN1/LAN1 or WAN2/LAN2 port
of the RCM.
Issue 01 (2024-07-31)
NO TE
● For the SmartLogger installed inside the ESS, see
SmartLogger.
● For the SmartLogger installed outside the ESS, see
Copyright © Huawei Digital Power Technologies Co., Ltd.
7 Installing Cables
7.6 (Optional) Installing the
SmartLogger3000 Quick Guide.
