LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Check Item
Issue 01 (2024-07-31)
Criteria
Check that ground cables of the
PACK, PCS, RCM, LTMS, and LCC
are connected.
If the ground cables are not
connected, contact your vendor.
Check whether the BAT+ and
BAT– terminals on the RCM side
are connected to cables, and
whether the general power
terminals on the PACK side are
disconnected from the RCM.
If the cables on the RCM side are
not connected or the terminals
on the PACK side are not
disconnected, contact your
vendor.
Check whether the LTMS coolant
is above the Min scale.
If the coolant is insufficient, refill
the coolant promptly.
Check that all switches of the
PACK, PCS, RCM, and LTMS are
turned off.
If the switches are not turned off,
contact your vendor.
Check whether cables of the
PACK, PCS, RCM, and LTMS are
connected.
If the cables are not connected,
contact your vendor.
(Optional) Check whether the
PACK-level TRSD is available and
whether cables are properly
connected.
If the PACK-level TRSD cables are
not connected, contact your
vendor.
Copyright © Huawei Digital Power Technologies Co., Ltd.
6 Installation
Precaution
None
None
None
None
None
This check item applies
to the ESS equipped
with a PACK-level TRSD.
75
