LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Figure A-1 Requirements on an OT or DT terminal
Crimping an OT or DT Terminal
● Avoid scratching the core wire when stripping a cable.
● The cavity formed after the conductor crimp strip of the OT or DT terminal has
● Wrap the wire crimping area with heat shrink tubing or insulation tape. The
● Use a heat gun carefully to avoid heat damage to the equipment.
Issue 01 (2024-07-31)
NO TICE
been crimped must wrap around the core wire completely. The core wire must
make close contact with the OT or DT terminal.
heat shrink tubing is used as an example.
Copyright © Huawei Digital Power Technologies Co., Ltd.
A Crimping an OT or DT Terminal
115
