LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
No.
8
9
10
Issue 01 (2024-07-31)
Item
SOC
indicator
Air outlet of
the heat
sink
Air inlet of
the heat
sink
Copyright © Huawei Digital Power Technologies Co., Ltd.
Maximum Description
Quantity
per ESS
1 Consists of 10 rectangular LEDs that
display the SOC status of the ESS in real
time through the number of sequential
blinking LEDs.
For example:
● When the ESS is charging from 60%
to 70% SOC, the first to sixth LEDs
are steady green, and the seventh to
tenth indicators are blinking in
sequence. When the ESS is fully
charged, 10 LEDs are all steady on.
● When the ESS is discharging from
70% to 60% SOC, the first to sixth
LEDs are steady green, the seventh
LED is blinking slowly, and the
eighth to tenth LEDs are off. When
the ESS is fully discharged, 10 LEDs
are all off.
● When the ESS is not charged or
discharged, for example at 70% SOC,
the first to seventh indicators are
steady green, and the eighth to
tenth indicators are off.
1 Air outlet of the LTMS heat sink.
1 Air inlet of the LTMS heat sink, covered
with an air filter
