7.8 Follow-up Procedure

Seal the cable holes with sealing putty and ensure that there is no gap between
cables.
The forklift positioning plates are used to limit the positions of the forklift tynes
and prevent scratches on the ESS. The positioning plates can experience
deformation and paint damage due to collision, and are removed after the ESS is
installed.
Step 1 Install the RCM cover.
Figure 7-11 Installing the RCM cover
Step 2 After cables are installed, seal the PCS cable holes using the delivered sealing
putty.
