LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Technical Specifications
LTMS net weight
Cooling capacity
Refrigerant
Coolant
Design life
Environmental protection
Certification
Note:
[1] Battery side: ambient temperature 25°C/return water temperature 25°C;
power side: ambient temperature 25°C/return water temperature ≤ 70°C.
[2] For the entire LTMS, refrigerant content: 0.41 kg; CO
tons.

2.4.3.3 T/H Sensor

Figure 2-15 T/H sensor appearance
Technical Specifications
Temperature measurement range
Signal output
Issue 01 (2024-07-31)
[1]
NO TE
The appearance of the T/H sensor delivered onsite may vary.
Copyright © Huawei Digital Power Technologies Co., Ltd.
LTMS
92 kg
7.5 kW
[2]
R134a
50% ethylene glycol solution
10 years
RoHS, REACH, and WEEE
CE
equivalent: 0.5863
2
T/H Sensor
–20°C to +80°C
Two RJ45 ports, bidirectional cascading
2 Overview
