8.1.2 ESS Installation Check

Cabinet
No.
1
2
3
4
5
Interior
No.
1
2
3
4
5
6
7
8
Issue 01 (2024-07-31)
Check Item Acceptance Criteria
Installation ● The installation meets the design requirements.
● The cabinet is level, and each door opens normally.
Appearance The cabinet surface is free from cracks, dents, and
scratches. If the paint flakes off, repair the damaged
paint.
Cabinet Ground the cabinet correctly according to the
grounding requirements of the power distribution system.
Accessory The number and positions of accessories installed meet
design requirements.
Label All labels are correct, clear, and complete.
Check Item
Auxiliary power circuit breaker
Disconnector (optional)
Cable
Cable hole sealing
Components (PCS, RCM, BCU,
TRSD, and LTMS)
Foreign object
SPD
Power meter
Power meter fuse
Copyright © Huawei Digital Power Technologies Co., Ltd.
8 Powering On the ESS
Acceptance Criteria
The disconnector (optional) and
auxiliary power circuit breaker are
off.
The bolts for installing the cables
are tightened and the cables are
not loose.
Cable holes are sealed.
All components are intact.
Foreign objects such as tools and
remaining materials are cleared.
The SPD indicator is green.
The power meter is free from
cracks, dents, and damage, and its
buttons are normal.
The fuse is intact. Check that the
fuse is functioning using a
multimeter.
