LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
2.4.4.1 Thermal Runaway Suppression System Overview
Figure 2-18 Position of the thermal runaway suppression system
(1) Fire alarm horn/
strobe
(4) Heat detector
(7) Aerosol fire
suppression device
Issue 01 (2024-07-31)
Copyright © Huawei Digital Power Technologies Co., Ltd.
(2) Exhaust fan (optional) (3) Smoke detector
(5) CO sensor/Explosion-
proof CO sensor
(optional)
(8) Installation position
for the lead-acid battery
box
2 Overview
(6) PACK extinguishant
port (optional)
(9) TRSD host (optional)
46
