LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Table 2-16 DIP switch settings
T/H
Sensor
Address
56

2.4.3.4 Door Status Sensor

Figure 2-16 Appearance
(1) Switch
Technical Specifications
Connection method
Startup distance
Securing method
Hole spacing

2.4.3.5 Water Sensor

The water sensor detects water based on the resistance change between both
electrodes.
When the electrodes detect water, they are short-circuited and the BCU reports an
alarm.
Issue 01 (2024-07-31)
Toggle Toggle
Switch Switch 2
1
OFF OFF
Copyright © Huawei Digital Power Technologies Co., Ltd.
Toggle Toggle
Switch 3 Switch 4
OFF ON
(2) Magnet
Door Status Sensor
Wiring terminal
25–45 mm
Screw
40 mm±0.8 mm
2 Overview
Toggle Toggle
Switch 5 Switch 6
ON ON
44
