LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Figure 7-14 Installing the cable baffle plate
Step 5 Remove the forklift positioning plates from the ESS.
Figure 7-15 Removing forklift positioning plates
Step 6 Reinstall the external bottom baffle plate for the ESS.
Issue 01 (2024-07-31)
Copyright © Huawei Digital Power Technologies Co., Ltd.
7 Installing Cables
100
