Huawei Smart String ESS LUNA2000-215-2S10 User Manual page 93

LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Cable
Auxiliary
power
supply
cable
(through
the PCS
terminal)
UPS AC
input
power
cable
Network
cable
Optical
fiber
cable
Issue 01 (2024-07-31)
Type
Copper cable
Two-core/
Three-core
outdoor
copper/
copper-clad
aluminum/
aluminum
alloy cable
CAT 5E
outdoor
shielded
network
cable,
internal
resistance ≤
1.5 ohms/10
m
Four-core or
eight-core
single-mode
armored
cable with a
transmission
wavelength
of 1310 nm
Copyright © Huawei Digital Power Technologies Co., Ltd.
Cross- Terminal
Sectional
Area/
Outer
Diameter
Cross- ● The M6
sectional OT
area: 10 terminal
AWG end is
connecte
d to the
RCM.
● The M4
OT
terminal
end is
connecte
d to the
PCS.
Cross- M6 OT/DT
sectional terminal
area: 6–25
2
mm
Outer
diameter:
12.7–27
mm
≤ 9 mm Shielded
RJ45
connector
≤ 18 mm -
7 Installing Cables
Source Description
Delivered
with the
product
Prepared -
by the
customer
Delivered -
with the
product
Prepared -
by the
customer
86
