Huawei Smart String ESS LUNA2000-215-2S10 User Manual page 49

LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
●
●
Figure 2-14 LTMS appearance
Technical Specifications
Power system
Frequency
Operating temperature
Storage temperature
Operating humidity
LTMS dimensions (W x H x D)
Issue 01 (2024-07-31)
Natural cooling mode: In a low-temperature environment, the fan is used for
cooling the coolant which is supplied through the multi-way valve to cool the
PACK and PCS.
Heating mode: When the PACK temperature is too low, the LTMS
automatically adjusts the multi-way valve based on the ambient temperature
to implement three heating modes: heat pump, waste heat recovery, and
electric heater.
Copyright © Huawei Digital Power Technologies Co., Ltd.
LTMS
200–240 V AC, 1 PH
50/60 Hz
–30°C to +55°C
–35°C to +60°C
5%–95% RH
660 mm x 1560 mm x 240 mm
2 Overview
42
