LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Item
Rated charge and
discharge current of
the system
Rated charge and
discharge current of
the system (1.1 times
overload)
Rated charge and
discharge current of
the system (1.2 times
overload)
Rated charge and
discharge current of
the system (1.3 times
overload)
Maximum charge
and discharge current
of the system
Rated power
Battery temperature
control mode
Rated cooling
capacity of the LTMS
LTMS model
LTMS quantity
Rated operating
pressure
Maximum operating
pressure
Dimensions (W x D x
H)
Weight
IP rating
Operating
temperature range
Issue 01 (2024-07-31)
LUNA2000-215-2S10
164.1 A @ 380 V AC
155.9 A @ 400 V AC
150.3 A @ 415 V AC
180.5 A @ 380 V AC
171.5 A @ 400 V AC
165.3 A @ 415 V AC
197.0 A @ 380 V AC (1
min)
187.1 A @ 400 V AC (1
min)
180.4 A @ 415 V AC (1
min)
213.4 A @ 380 V AC (5s)
202.7 A @ 400 V AC (5s)
195.4 A @ 415 V AC (5s)
221.1 A
108 kW
Liquid cooling
7.5 kW
LunaTMS2000-H008SG00
1
0.15 MPa
0.2 MPa
1150 mm x 1800 mm x 2100 mm
≤ 2.8 t
IP55
–30°C to +55°C (derated above 50°C)
Copyright © Huawei Digital Power Technologies Co., Ltd.
11 Technical Specifications
LUNA2000-215-2S12
164.1 A @ 380 V AC
155.9 A @ 400 V AC
180.5 A @ 380 V AC
171.5 A @ 400 V AC
197.0 A @ 380 V AC (1
min)
187.1 A @ 400 V AC (1
min)
213.4 A @ 380 V AC (5s)
202.7 A @ 400 V AC (5s)
112
