LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Item
Maximum charge efficiency
Table 2-9 Protection
Item
Overvoltage category
AC surge protection
Insulation resistance detection
Anti-islanding protection
Output overcurrent protection
Residual current monitoring
Input reverse connection
protection
Table 2-10 General specifications
Item
Dimensions (W x H x D)
Weight
Ingress protection (IP) rating
Cooling mode
PCS electromagnetic compatibility (EMC) warning: This PCS is not intended for
independent use in a residential environment, and this PCS may cause radio
interference, in which case the user may be required to take additional
mitigation measures against electromagnetic interference. When the PCS is
installed in this Smart String ESS, this restriction does not apply.

2.4.1.4 RCM

The ESS supports the following RCMs:
●
●
Issue 01 (2024-07-31)
RCM-M1-C-140A1 (0.5CP, without disconnector)
RCM-M1-S-140A1 (0.5CP, with disconnector)
Copyright © Huawei Digital Power Technologies Co., Ltd.
PCS
98.60%
PCS
OVCⅡ (DC)/OVCⅢ (AC)
Type II, 5 kA (8/20 μs)
Supported
Supported
Supported
Supported
Supported
PCS
≤ 820 mm x 160 mm x 973 mm (excluding
mounting ears and terminals)
≤ 105 kg (excluding coolant)
IP55
Smart liquid cooling
2 Overview
34
