Security fencing:
It is recommended that physical walls or fences be used for isolation and
protection in the energy storage equipment area. The fences shall be equipped
with a door lock and the recommended fence height is greater than 2.2 m. Fire
walls shall be permitted to be substituted for part or all of the fences, depending
on the actual design plans.
Issue 01 (2024-07-31)
▪
If either of the following conditions is met, the distance between the
ESS and the production building shall be permitted to be reduced to
3 ft (0.914 m). In addition, clearance requirements for equipment
transportation, installation, and maintenance shall be considered.
○
There are 1-hour freestanding fire walls, extending 5 ft (1.5 m)
above and extending 5 ft (1.5 m) beyond the physical boundary
of the ESS installation.
○
Non-combustible exterior walls with no openings or combustible
overhangs are provided on the walls adjacent to the ESS and the
fire resistance rating of the exterior walls complies with 2-hour
fire resistance rating of ASTM E119 or UL 263.
▪
The distance between the exhaust device of an ESS and the heating
and ventilation vents, air intake vents of air conditioners, windows,
doors, unloading platforms, and fire sources of other buildings or
facilities must be greater than 4.6 m.
▪
In areas where no standards or requirements are applicable, the
distance between the ESS and production buildings can be reduced
to greater than 0.4 m.
The ESS shall not be installed in salt-affected or polluted areas because this
will cause corrosion. The ESS shall be used in the following or better
environments:
– Outdoor environment more than 2000 m away from the coast. You are
advised not to use the ESS in an area within 2000 m of the coast. (If you
need to use it, confirm with the vendor or the Company's engineers.)
– More than 3000 m away from heavy pollution sources such as smelteries,
coal mines, and thermal power plants
– More than 2000 m away from medium pollution sources such as
chemical, rubber, and electroplating industries
– More than 1000 m away from light pollution sources such as packing
houses, tanneries, boiler rooms, slaughterhouses, landfill sites, and
sewage treatment plants
NO TE
You are advised to select another site if the safety distance for a site cannot meet the
requirements of relevant national standards.
