LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Technical Specifications
Dimensions (diameter x height)
Installation mode
Table 2-20 Indicator description
Name
Indicator

2.4.4.7 Fire Alarm Horn/Strobe

A fire alarm horn/strobe consists of a control board, alarm indicators, and a
buzzer. After receiving warning signals from devices such as the heat detector and
smoke detector, the fire alarm horn/strobe starts and generates audible and visual
alarm signals indicating potential dangers.
Figure 2-25 Fire alarm horn/strobe

2.4.4.8 Exhaust Fan (Optional)

The exhaust fan is the actuator of the active exhaust system. When the
combustible gas is released from the battery, the exhaust fan reduces the
concentration of combustible gas in the battery cabin.
Issue 01 (2024-07-31)
Color
Red
NO TE
Only some models are equipped with the exhaust fan.
Copyright © Huawei Digital Power Technologies Co., Ltd.
Smoke Detector
110 mm x 60 mm (with a base)
Securing with screws
Status
Steady on
Blinking
2 Overview
Description
The detector
enters the alarm
state.
The detector
enters the
monitoring state.
51
