LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
2.4.1.1 Power Supply and Distribution System Overview
Figure 2-5 Position of the power supply and distribution system
(1) PACK
2.4.1.2 PACK
The ESS supports three types of PACKs:
●
●
Issue 01 (2024-07-31)
LUNA2000-54-2E1 (with PACK extinguishant port)
LUNA2000-54-2E1 (without PACK extinguishant port)
Copyright © Huawei Digital Power Technologies Co., Ltd.
(2) PCS
2 Overview
(3) RCM
30
