2.4.3.1 Environment Control System Overview
Figure 2-13 Position of the environment control system
(1) LTMS
(4) Travel switch
2.4.3.2 LTMS
The LTMS consists of the compressor, fan, pump, heat exchanger, and multi-way
valve, and supports intelligent selection of cooling and heating modes.
●
Issue 01 (2024-07-31)
Mechanical cooling mode: In a high-temperature environment, the coolant is
supplied through the multi-way valve to cool the PCS, and the compressor is
used for cooling the coolant which is supplied to cool the PACK.
Copyright © Huawei Digital Power Technologies Co., Ltd.
(2) T/H sensor
(5) Water sensor
2 Overview
(3) Door status sensor
41
