LUNA2000-(215-2S10, 215-2S12) Smart String ESS
User Manual
Figure 7-6 Connecting communications cables (for the SmartLogger installed
outside the ESS)
(1) White-and-
orange
(5) White-and-
blue
Step 2 Bind the cable.
----End

7.5.2 Installing Optical Fiber Communications Cables

Only professionals are allowed to connect optical fiber cables and splice fibers.
Issue 01 (2024-07-31)
(2) Orange
(6) Green
NO TICE
NO TE
In the optical fiber ring topology, two optical fiber cables are required.
Copyright © Huawei Digital Power Technologies Co., Ltd.
(3) White-and-
green
(7) White-and-
brown
7 Installing Cables
(4) Blue
(8) Brown
93
