6.2 Preparing Tools

Installati
on tool
Issue 01 (2024-07-31)
NO TE
● The tool pictures are for reference only.
● The tool tables may not list out some tools required onsite. Onsite installation personnel
and the customer need to prepare the tools based on the site requirements.
Phillips
insulated
torque
screwdriver
Wire stripper
RJ45 crimping
tool
Copyright © Huawei Digital Power Technologies Co., Ltd.
Insulated Flat-head
torque socket insulated
wrench torque
(including an screwdriver
extension bar)
● Socket
specification
s: 7–19 mm
● Socket depth
≥ 32 mm
● The socket
connector
matches the
torque
wrench.
● Torque
range: 1.2–
45 N·m
Cable cutter Rubber mallet
Hydraulic pliers Needle-nose
pliers
6 Installation
Diagonal pliers
Utility knife
Marker
