Modulite
3.20.5 Adjusting Footrests
Adjusting Angle–adjustable Footrests
5 mm Allen key
l
1. Loosen both set screws on the
2. Adjust to the desired angle.
3. Re-tighten the screws.
Adjusting Angle– and Depth–adjustable Footrests
5 mm Allen key
l
1. Loosen the set screw on the footrest
2. Adjust the footrest to the desired
A
3. Re-tighten the screw.
50
footrest.
A.
angle or depth.
3.21 Adjusting Standard 80° Legrest
Swivelling and / or Removing
1. Push release lever A inward or
2. Adjust component to desired position.
3. Pull upward to remove component.
Adjusting Length
1. Loosen screw A.
2. Adjust component to desired
3. Tighten screw.
outward.
Do not remove screw A.
position.
1656515-G
