4 Usage
4.1 Removing Armrest for Side Transfer
Flip-up Armrest
Following Armrest
1. Pull knob A to unlock armrest support B
from bearing plate C.
2. Flip up armrest for side transfer.
For more information about side transfer, see the user manual
of the power wheelchair.
1656515-G
1. Flip up armrest for side transfer.
4.2 Removing / Inserting Hip Support with
Quick Release
Removing Hip Support
1. Pull lever A upwards.
2. Remove hip support from holder.
Inserting Hip Support
1. Insert hip support in holder.
2. Push lever A downwards. Ensure
that hip support locks with an
audible click.
