Invacare Modulite User Manual page 60

Modulite
Dimensions According
to ISO 7176-5
Armrest Height Telescopic Seat Frame [mm]
T-Armrest
Flip-up Armrest
Following Armrest
Armrest Height One Piece Seat Plate [mm]
T-Armrest
2
Armrest Depth [mm]
Max. Armrest Weight [kg]
Max. Headrest Weight [kg]
Seat Angle, Electrical A djustment (Tilt Only Module 50° [T] / Tilt with Lifter 45° [T / L])
Standard Mount
5° Fixed Anterior Mount
10° Fixed Anterior Mount
5° Fixed Posterior Mount
Seat Angle, Electrical Adjustment (30°)
Standard Mount
5° Fixed Anterior Mount
Seat Angle, Electrical Adjustment (20°)
60
Power W heelchair
TDX S P2 (Standard) AVIVA RX (Standard)
230 – 360
l
230 – 300 / 300 – 360
l
275 – 340 / 325 – 390
l
max. 440
l
0° ... 50 (T) / 0° ... 45° (T / L)
l
–5° ... 45° (T) / –5° ... 40°(T / L)
l
–10° ... 40° (T) / –10° ... 35° (T / L)
l
5° ... 55° (T) / 5° ... 50° (T / L)
l
-5°... +25°
l
AVIVA R X (HD)
245 – 310 / 295 – 360
l
—
l
—
l
—
l
325 – 397
l
1.7
l
1.4
l
—
l
—
l
—
l
—
l
0° ... +30°
l
—
l
AVIVA F X
230 – 360
l
230 – 300 /
l
300 – 360
—
l
—
l
—
l
—
l
—
l
